Silver Belt Drive Linear Drive Unit With Stroke Length From 299mm To 2999mm

Place of Origin Germany
Brand Name ISEL
Certification IPA, CE certification
Model Number LES4
Minimum Order Quantity 1 pcs
Price USD, negotiable
Packaging Details nonwooden box
Delivery Time 5-6 weeks
Payment Terms T/T, 30%payment in advance, 70% payment before delivery
Supply Ability 100pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material AIMGSiO,5F22 Anodising E6/EV1
Weight With Steel Shafts And Spindles LES4: 7.6kg/m, Speed Range 31mm-1333mm/s
Max. Load 200kg Drive Direct Drive Module Or Belt Drive Module
Shaft Slides Shaft Slides 70mm Or Shaft Slides 200mm Recirculating Ball Drive Pitch 2.5, 4, 5, 10, 20 Mm
Profile Length 290-2990mm Repeat Accuracy ± 0.02 Mm
High Light

electric linear actuator

,

miniature linear actuator

,

Silver Belt Linear Drive Unit

Leave a Message
Product Description

LES4, direct drive or belt drive, stroke length from 299mm to 2999mm








Features






• Aluminium shaft housing profile
  W150*H75 mm,naturally anodized

• clamping area and profile underside milled flat

• with 4 precision steel shafts
  Φ12 h6,material Cf53,hardness 60±2 HRC

• aluminium shaft slides WS 5/70,
  2*WS 5/70(70 mm long),adjustable for no play,central lubrication system

• recirculating ball drive 2.5/4/510 and 20 mm pitches

• profile sealing with friction-resistant lip seals

• cast aluminum end plates

• with 2 limit or reference switches,repeat accuracy±0.02mm

• sealed angular contact bearings in drive-steel flange


















Options






• black anodized aluminium profile

• electromagnetic brake

• steel slides LS2 (Part no. 223007)

• limit switch attachment kit













Available on request







• length measuring system

• bellows gaiter cover

• assembly left of the motor module













Ordering key






2 3 4   X X X   0 X X X

           ↓  ↓  ↓          ↓

          ① ② ③         ④




① Drive

     0 : Preparation
     Direct drive modules

     1 : Preparation
     Belt drive modules



② Shaft slides

      0 : 1 shaft slides 70 mm

 1 : 1 shaft slides 200 mm

 2 : 2 shaft slides 70 mm




③ Recirculating ball drive

     0 : without
     1 : Pitch 2.5 mm
     2 : Pitch 4.0 mm
     3 : Pitch 5.0 mm
     4 : Pitch 10 mm
     5 : Pitch 20 mm
     6 : Pitch 20 mm (with complete ball return)



④ Profile length (L1)

      e.g. 029 : 290 mm (min.)
             299 : 2990 mm (max.)

      (rounded to the last digit)

       Standard profile lengths available in 100 mm raster.













No load running torques










No load torques (Ncm)

Speed

(rpm)

Spindle pitch
2.5 4 5 10 20
500 17 17 18 20 21
1500 20 20 22 24 25
3000 24 25 26 29 30

















Dimensioned drawing










Silver Belt Drive Linear Drive Unit With Stroke Length From 299mm To 2999mm 0

















Applications








Appliied for 3 axis combination, CNC machine for different applications







Silver Belt Drive Linear Drive Unit With Stroke Length From 299mm To 2999mm 1
