Long Stroke Transportation Robot 7 Axis With Organ Cover Dustproof Modes
| Place of Origin | China |
|---|---|
| Brand Name | TJ |
| Certification | ISO9001:2008,ISO14001:2004 |
| Model Number | TJS XX SXXX VXX AXX LX EX X |
| Minimum Order Quantity | 1 pcs |
| Price | negotiable |
| Packaging Details | non wooden box |
| Delivery Time | 6~8 weeks |
| Payment Terms | T/T,30% payment in advance,70% before delivery |
| Supply Ability | 10 pcs per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Repeatability | ±0.1mm | Velocity | ≤3m/s |
|---|---|---|---|
| Load | ≤6t | Accelertaion | ≤5m/s² |
| Stroke | ≤70m | Lubricating System | Manual/automatic |
| Dustproof Modes | Sheet Metal Cover/organ Cover | Drag Chain Material | Engineering Plastics/steel/stainless Steel |
| High Light | robot rail system,robot linear track,Long Stroke Transportation Robot 7 Axis |
||
Product Description
long stroke robot rail max. 70m,high safety 7th robot axis used for transportation
Basic configurations
Features and benefits
1. Customized travel. According to the customer requirement the 7th axis can be extended to 70 m.
2. Flexible installation, high precision. The 7th axis is bolted to the ground by using adjustable floor-mounting elements. This ensures a fast and accurate installation and allows for uneven ground as well as obstacles such as wiring and tubing.
3. High safety. We have to set the limit switch and add the mechanical safety limit to prevent the accidental derailment of the articulate robot and ensure the safe and reliable operation of the robot.
4.Environmental Protection.On 7th axis we can assemble with organ shield for guide rail, dust prevention and non-pollution, easy maintenance.
Model definition
①TJS ②05 ③S040 ④V08 ⑤A08 ⑥L1 ⑦E1 ⑧2
| ①TJ 7th - Axis Robot |
③Stroke
S004:0.4m S040:4m A300:70m Select any value within 79mm.
|
⑤Acceleration
A05:0.5m/s² A08:0.8m/s² A10:1.0m/s² A15:1.5m/s²
|
⑦Dustproof modes
E1:sheet metal cover E2:organ cover E3:others
|
|
②Load
0.8:800kg 15:1.5t 30:3t
|
④Speed
V08:0.8m/s A10:1m/s Select any value within 3m/s.
|
⑥Lubricating system
L1:manual L2:automatic L3:others
|
⑧Drag chain
1:engineering plastics 2:steel 3:stainless steel 4:others
|
FAQ
Q:What's the price of the product?
A:The price is based on the specification and accessories(servo motor,gearbox,guideway and so on.If you need,we can also send you a copy of customer requirement list.You can provide us the detailed information and specific requires then we will make the model selection for you and give you the formal offer.
Q:Which countries and regions do your products export to?
A:Germany,Italy,Brazil,Mexico,Japan,Iran,France,India etc.Mainly used for vehicle assembly,flame plating,loading and unloading,stacking etc.
Q:Can you also provide us the robot if we want a complete set of processing solution?
A:Yes,sure.we have much experience in system integration.You just tell us your application and the effect you want.By the way,we have a good cooperative relationship with some robot manufacturers such as FANUC,ABB,YASKAWA,Panda,ESTUN,EFORT etc.So we also take advantages in the price of the robots.
No matter you only need robot rail or the whole system,we can both meet your requirements.
